| Nombor Bahagian | LB070WV8-SL01 |
| Jenama | LG Display |
| Saiz | 7.0 |
| Permohonan | CNS |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | LG Display |
| model panel | LB070WV8-SL01 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | IPS, Normally Black, Transmissive |
| kawasan aktif | 152.4×91.44 mm |
| garis besar | 170×106.3×10.7 mm |
| permukaan | Antiglare |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193160% |
| masa tindak balas | 15/10 (Typ.)(Tr/Td) |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 8-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | CNS |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LB070WQ4-TM06 | LG Display | 7.0 | 480×234 |
| LB070WQ5-TD01 | LG Display | 7.0 | 480×240 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LB070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD12 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD17 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD01 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD02 | LG Display | 7.0 | 800×480 |
| AT080TN03 V.2 | Innolux | 8.0 | 800×480 |
| C070VW02 V0 | AUO | 7.0 | 800×480 |
| L5F30818P04 | SONY | 6.5 | 800×480 |
| LA070WV6-SL01 | LG Display | 7.0 | 800×480 |
| LA080WV2-TD01 | LG Display | 8.0 | 800×480 |
| LA080WV4-SD03 | LG Display | 8.0 | 800×480 |
| LA092WV1-SD01 | LG Display | 9.2 | 800×480 |
| LAJ084T001A | TPO | 8.4 | 800×600 |
| TM050LDZ00 | Tianma | 5.0 | 240×400 |
| TM062RDZG10 | Tianma | 6.2 | 800×480 |
