| Nombor Bahagian | LA123WF4-SR08 |
| Jenama | LG Display |
| Saiz | 12.3 |
| Permohonan | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 8S6P |
| Antara muka | |
| pengilang | LG Display |
| nama model | LA123WF4-SR08 |
| saiz skrin | 12.3 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×720 167PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 292.032 × 109.512 (H×V) |
| garis besar (mm) | 310 × 128 × 10.75 (H×V×D) |
| kawasan bezel (mm) | 296.03 × 113.5 (H×V) |
| rawatan | Hard coating |
| kecerahan | 600 cd/m² (Min.) |
| nisbah kontras | 800 : 1 (Min.) (TM) |
| sudut pandangan | 89/89/89/89 (Min.)(CR≥10) |
| tindak balas | 30 (Max.)(G to G); 30 (Typ.)(MPRT) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | IPS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 77% NTSC |
| lampu latar | 8S6P WLED , 10K hours , No Driver |
| jisim | - |
| digunakan untuk | Automotive Display |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
