| Nombor Bahagian | LA090WH1-SL01 |
| Jenama | LG Display |
| Saiz | 9.0 |
| Permohonan | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | LG Display |
| model | LA090WH1-SL01 |
| saiz pepenjuru | 9.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×720 [WXGA] 164PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 200.448(H)×106.056(V) mm |
| garis besar malap. | 213.2(H)×121.2(V) ×8.6(D) mm |
| kawasan bezel | 203.148(H)×108.756(V) mm |
| rawatan | Antiglare |
| kecerahan | 600 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 17/13 (Max.)(Tr/Td) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥10) |
| mod operasi | IPS, Normally Black, Transmissive |
| warna sokongan | 16.7M 65% NTSC |
| sumber cahaya | WLED [6S3P] , 10K hours , W/O Driver |
| berat badan | 219/224g (Typ./Max.) |
| direka untuk | Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 8-bit) , 60 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
