| Nombor Bahagian | KCS6448ESTT-X1 |
| Jenama | Kyocera |
| Saiz | 7.7 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | LCM, CSTN-LCD |
| Kecerahan | |
| CR | 20:1 |
| Warna | Color |
| Lampu latar | CCFL |
| Antara muka | |
| pengilang | Kyocera |
| nama model | KCS6448ESTT-X1 |
| saiz skrin | 7.7 inch |
| jenis skrin | LCM, CSTN-LCD |
| nombor piksel | 640(RGB)×480 (VGA) 103PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 157.42 × 118.06 (H×V) |
| garis besar (mm) | 199 × 147 × 10.5 (H×V×D) |
| kawasan bezel (mm) | 160.42 × 121.06 (H×V) |
| rawatan | Antiglare |
| kecerahan | - |
| nisbah kontras | 20 : 1 (Typ.) (TM) |
| sudut pandangan | 50/50/40/30 (Typ.)(CR≥2) |
| tindak balas | 160/80 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | - |
| mod kerja | STN, Normally Black, Transmissive |
| kedalaman warna | Color |
| lampu latar | CCFL |
| jisim | - |
| digunakan untuk | Industrial |
| kadar segar semula | 75Hz |
| skrin sentuh | Without |
| Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
