| Nombor Bahagian | JJ070IA-18L |
| Jenama | Innolux |
| Saiz | 7.0 |
| Permohonan | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 7S2P |
| Antara muka | LVDS |
| pengilang | Innolux |
| saiz skrin | 7.0 inch |
| nombor piksel | 800(RGB)×480 (WVGA) 133PPI |
| kawasan aktif (mm) | 152.4 × 91.44 (H×V) |
| kawasan bezel (mm) | 155.4 × 94.44 (H×V) |
| kecerahan | 750 cd/m² (Typ.) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 70% NTSC |
| jisim | 195±9g |
| kadar segar semula | 60Hz |
| jenis isyarat | LVDS (1 ch, 8-bit) , 50 pins FPC |
| bekalan voltan | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| maks. penilaian | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| nama model | JJ070IA-18L |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 162.8 × 104.84 (H×V×D) |
| rawatan | Antiglare |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| tindak balas | 15/10 (Typ.)(Tr/Td) ms |
| mod kerja | IPS, Normally Black, Transmissive |
| lampu latar | 7S2P WLED , 20K hours , No Driver |
| digunakan untuk | Automotive Display |
| skrin sentuh | Without |
