HSD190ME12-A10

HSD190ME12-A10
HSD190ME12-A10 thumb
Jenama
HannStar
Saiz
19.0
Permohonan
DMPC
Resolusi
1280×1024
Komposisi
LCM
Kecerahan
250
CR
700:1
Warna
16.2M
Lampu latar
CCFL
Antara muka
LVDS
In Stock
8523
Spesifikasi

Nombor Bahagian HSD190ME12-A10
JenamaHannStar
Saiz19.0
PermohonanDMPC
Resolusi1280×1024
KomposisiLCM
Kecerahan250
CR700:1
Warna16.2M
Lampu latarCCFL
Antara mukaLVDS
jenama panelHannStar
model panelHSD190ME12-A10
jenis panel a-Si TFT-LCD , LCM
saiz panel19.0 inch
resolusi1280(RGB)×1024 , SXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif376.32×301.056 mm
garis besar404.2×330×19.5 mm
permukaanAntiglare, Hard coating (3H)
kecerahan250 cd/m² (Typ.)
nisbah kontras700:1 (Typ.)
warna paparan16.2M (6-bit + FRC)
masa tindak balas2/6 (Typ.)(Tr/Td)
sudut pandangan75/75/70/65 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampu4 pcsCCFLWithout Driver
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanDMPC
Model Keluarga
HSD190ME12-A02 HannStar 19.0 1280×1024
HSD190ME12-A10 HannStar 19.0 1280×1024
HSD190ME13-A13 HannStar 19.0 1280×1024
HSD190ME13-D10 HannStar 19.0 1280×1024
HSD190MEN3-A00 HannStar 19.0 1280×1024
HSD190MEN3-A03 HannStar 19.0 1280×1024
HSD190MEN4-A03 HannStar 19.0 1280×1024
HSD190MEN6-A00 HannStar 19.0 1280×1024
HSD190MEN6-A01 HannStar 19.0 1280×1024
HSD190MGW1-B00 HannStar 19.0 1440×900
