| Nombor Bahagian | HSD150GXN1-A00-C00 |
| Jenama | HannStar |
| Saiz | 15.0 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 700:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | HannStar |
| saiz pepenjuru | 15.0 inch |
| format piksel | 1024(RGB)×768 [XGA] 85PPI |
| kawasan aktif | 304.128(H)×228.096(V) mm |
| kawasan bezel | 307.4(H)×231.3(V) mm |
| kecerahan | 250 cd/m² (Typ.) |
| arah pandang | - |
| sudut pandangan | 80/80/60/80 (Typ.)(CR≥10) |
| warna sokongan | 262K/16.2M 60% NTSC |
| berat badan | 1.20Kgs (Max.) |
| kadar bingkai | 60Hz |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
| model | HSD150GXN1-A00-C00 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 326.5(H)×253.5(V) ×12.7(D) mm |
| rawatan | - |
| nisbah kontras | 700:1 (Typ.) (TM) |
| masa tindak balas | 12 (Typ.)(Tr+Td) |
| mod operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED , 30K hours , With LED Driver |
| direka untuk | Industrial |
| panel sentuh | Embeded Touch |
