| Nombor Bahagian | HSD123KPW2-A10 |
| Jenama | HannStar |
| Saiz | 12.3 |
| Permohonan | Automotive Display |
| Resolusi | 1920×720 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1100:1 |
| Warna | 16.7M |
| Lampu latar | 11S4P |
| Antara muka | LVDS |
| pengilang | HannStar |
| saiz skrin | 12.3 inch |
| nombor piksel | 1920(RGB)×720 167PPI |
| kawasan aktif (mm) | 292.032 × 109.512 (H×V) |
| kawasan bezel (mm) | 294.8 × 112.1 (H×V) |
| kecerahan | 850 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 70% NTSC |
| jisim | TBD |
| kadar segar semula | 60Hz |
| jenis isyarat | LVDS (2 ch, 8-bit) , 50 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| nama model | HSD123KPW2-A10 |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 308.1 × 130 × 15.6 (H×V×D) |
| rawatan | Glare (Haze 0%) |
| nisbah kontras | 1100 : 1 (Typ.) (TM) |
| tindak balas | 16/14 (Typ.)(Tr/Td) ms |
| mod kerja | IPS Pro, Normally Black, Transmissive |
| lampu latar | 11S4P WLED , 30K hours , No Driver |
| digunakan untuk | Automotive Display |
| skrin sentuh | Without |
