| Nombor Bahagian | HSD104IXN1-A01-0299 |
| Jenama | HannStar |
| Saiz | 10.4 |
| Permohonan | Industrial Automotiv |
| Resolusi | 1024×768 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.2M |
| Lampu latar | No |
| Antara muka | |
| pengilang | HannStar |
| saiz skrin | 10.4 inch |
| nombor piksel | 1024(RGB)×768 (XGA) 123PPI |
| kawasan aktif (mm) | 211.2 × 158.4 (H×V) |
| kawasan bezel (mm) | - |
| kecerahan | 0 (cd/m²) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| ketebalan kaca | 0.50+0.50 mm |
| kedalaman warna | 262K/16.2M 70% NTSC |
| jisim | 100±10g |
| kadar segar semula | 60Hz |
| nama model | HSD104IXN1-A01-0299 |
| jenis skrin | CELL , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 220.9 × 168.75 × 1.3 (H×V×D) |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 900 : 1 (Typ.) (TM) |
| mod kerja | IPS Pro, Normally Black, Transmissive |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| ketransmisian | 4.68% (Typ.)(with Polarizer) |
| lampu latar | No B/L |
| digunakan untuk | Industrial Automotive Display |
| skrin sentuh | Without |
