| Nombor Bahagian | HX104X02-100 |
| Jenama | HYDIS |
| Saiz | 10.4 |
| Permohonan | PAD |
| Resolusi | 1024×768 |
| Komposisi | LCM |
| Kecerahan | 340 |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | HYDIS |
| model panel | HX104X02-100 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.4 inch |
| resolusi | 1024(RGB)×768 , XGA |
| mod paparan | AFFS+, Normally Black, Transmissive |
| kawasan aktif | 210.4×157.8 mm |
| garis besar | 238.6×173.2×6.8 mm |
| permukaan | Antiglare, Antireflection |
| kecerahan | 340 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193140% |
| masa tindak balas | 36 (Typ.)(Tr+Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 7S6PWLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
