| Nombor Bahagian | HSD070F6W1-F |
| Jenama | HannStar |
| Saiz | 7.0 |
| Permohonan | Digital Photo Frame |
| Resolusi | 480×234 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 350:1 |
| Warna | Full |
| Lampu latar | No |
| Antara muka | Analog |
| jenama panel | HannStar |
| model panel | HSD070F6W1-F |
| saiz panel | 7.0" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 480(RGB)×234, 76PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 154.08(W)×86.58(H) mm |
| pembukaan bezel | - |
| kecerahan | 0 cd/m² |
| nisbah kontras | 350:1 (Typ.) (TM) |
| sudut pandangan | - |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | - |
| masa tindak balas | - |
| warna paparan | Full color |
| jenis lampu | No B/L |
| kekerapan | - |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Digital Photo Frame Portable DVD Player |
| antara muka isyarat | Analog RGB |
| persekitaran | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C |
| HSD070IDW1-A00 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-A20 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-A21 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-A30 | HannStar | 7.0 | 800×480 |
| HSD070IDW1-E11 | HannStar | 7.0 | 800×480 |
| HSD070IFW1-B00 | HannStar | 7.0 | 1024×600 |
| HSD070ISN1-D00 | HannStar | 7.0 | 800×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
