| Nombor Bahagian | HSD070BHW1-A00 |
| Jenama | HannStar |
| Saiz | 7.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 720×1280 |
| Komposisi | CELL , a-Si TFT-LC |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | |
| pengilang | HannStar |
| saiz skrin | 7.0 inch |
| nombor piksel | 720(RGB)×1280 (WXGA) 210PPI |
| kawasan aktif (mm) | 86.94 × 154.56 (H×V) |
| kecerahan | 0 cd/m² |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| ketebalan kaca | 0.40+0.40 mm |
| kedalaman warna | 16.7M 70% NTSC |
| jisim | - |
| kadar segar semula | - |
| senarai ic pemandu | Built-in COG HX8394-A01, HX8394-B, NT35520, NT35521, OTM1283A, OTM1288A |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| nama model | HSD070BHW1-A00 |
| jenis skrin | CELL , a-Si TFT-LCD |
| susunan | RGB Ttilt Stripe |
| garis besar (mm) | 89.94 × 162.56 × 0.8 (H×V×D) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| tindak balas | 10/20 (Typ.)(Tr/Td) ms |
| mod kerja | IPS Pro, Normally Black, Transmissive |
| ketransmisian | 4.0% (Typ.)(with Polarizer) |
| lampu latar | No B/L |
| digunakan untuk | Pad & Tablet |
| skrin sentuh | Without |
| A070VTN03.0 | AUO | 7.0 | 800×480 |
| A070VW04 V3 | AUO | 7.0 | 800×480 |
| A070XN01 V0 | AUO | 7.0 | 1024×768 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AT070TN82 | Innolux | 7.0 | 800×480 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| HE070IA-04R | Innolux | 7.0 | 800×1280 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LQ070T5DR02 | SHARP | 7.0 | 480×240 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
