| Nombor Bahagian | H546TAN01.0 |
| Jenama | AUO |
| Saiz | 5.5 |
| Permohonan | MPH |
| Resolusi | 720×1280 |
| Komposisi | LCM |
| Kecerahan | 440 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | AUO |
| model panel | H546TAN01.0 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 5.5 inch |
| resolusi | 720(RGB)×1280 , WXGA |
| mod paparan | AHVA, Normally Black, Transmissive |
| kawasan aktif | 68.04×120.96 mm |
| garis besar | 72.3×130.39×1.75 mm |
| permukaan | |
| kecerahan | 440 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193170% |
| masa tindak balas | 35 (Max.)(Tr+Td) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDWithout Driver |
| antara muka isyarat | MIPI (4 data lanes) |
| voltan masukan | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| permohonan | MPH |
