| Nombor Bahagian | H546DLK01.0 |
| Jenama | AUO |
| Saiz | 5.5 |
| Permohonan | Mobile Phone |
| Resolusi | 1080×1920 |
| Komposisi | AM-OLED , OLED |
| Kecerahan | |
| CR | 10000:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antara muka | MIPI |
| jenama panel | AUO |
| saiz panel | 5.5" |
| resolusi | 1080(RGB)×1920, FHD, 403PPI |
| kawasan paparan | 68.04(W)×120.96(H) mm |
| saiz garis besar | 70.84(W)×128.01(H) ×0.92(D) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandangan | 80/80/80/80 (Min.)(CR≥1600) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 100% NTSC |
| kekerapan | 100Hz |
| ic pemandu | COG Built-in RM69071 |
| berat panel | - |
| antara muka isyarat | MIPI (4 data lanes) |
| voltan masukan | 1.8/3.1/5.8/4.6/-2.9V (Typ.)(IOVCC/VCI/AVDD/OVDD/OVSS) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| model panel | H546DLK01.0 |
| jenis panel | AM-OLED , OLED |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating (3H) |
| nisbah kontras | 10000:1 (Min.) (TM) |
| mod paparan | - |
| masa tindak balas | - |
| jenis lampu | self |
| skrin sentuh | Embeded Touch |
| permohonan | Mobile Phone |
