| Nombor Bahagian | G649DX5R010 |
| Jenama | SII |
| Saiz | 8.9 |
| Permohonan | Industrial |
| Resolusi | 640×200 |
| Komposisi | FSTN-LCD, LCM |
| Kecerahan | |
| CR | 8:1 |
| Warna | Monochrome |
| Lampu latar | CCFL |
| Antara muka | Parallel |
| jenama | SII |
| model | G649DX5R010 |
| saiz pepenjuru | 8.9 inch |
| menaip | FSTN-LCD, LCM |
| format piksel | 640×200 75PPI |
| konfigurasi | Rectangle |
| kawasan aktif | 211.17(H)×79.17(V) mm |
| garis besar malap. | 260(H)×110.7(V) ×15(D) mm |
| kawasan bezel | 216.0(H)×83.2(V) mm |
| rawatan | - |
| kecerahan | 100 cd/m² (Typ.) |
| nisbah kontras | 8:1 (Typ.) (TM) |
| arah pandang | 6 o'clock |
| masa tindak balas | 250/150 (Typ.)(Tr/Td) |
| sudut pandangan | - |
| mod operasi | STN, Black/White (Negative), Transmissive |
| warna sokongan | Monochrome |
| sumber cahaya | CCFL [1 pcs] , 12K hours , W/O Driver |
| berat badan | 420g (Typ.) |
| direka untuk | Industrial |
| kadar bingkai | 70Hz |
| panel sentuh | Without |
| jenis antara muka | Parallel Data (1ch, 4-bit) PIN |
| bekalan kuasa | 5.0/-24.0V (Typ.)(VDD/VLC) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
