| Nombor Bahagian | G270ZAN01.3 |
| Jenama | AUO |
| Saiz | 27.0 |
| Permohonan | Industrial Medical I |
| Resolusi | 3840×2160 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 10S8P |
| Antara muka | eDP |
| pengilang | AUO |
| nama model | G270ZAN01.3 |
| saiz skrin | 27.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 3840(RGB)×2160 (UHD) 163PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 596.16 × 335.34 (H×V) |
| garis besar (mm) | 630 × 368.2 × 19.8 (H×V×D) |
| kawasan bezel (mm) | 602.0 × 340.4 (H×V) |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 16/25 (Typ./Max.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | AHVA, Normally Black, Transmissive |
| kedalaman warna | 16.7M 99% Adobe RGB |
| lampu latar | 10S8P WLED , 30K hours , No Driver |
| jisim | 3.30Kgs (Typ.) |
| digunakan untuk | Industrial Medical Imaging |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector |
| bekalan voltan | 12.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LM270WF1-TLD1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLB1 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SLM1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDF1 | LG Display | 27.0 | 2560×1440 |
| LM270WQ3-SLB2 | LG Display | 27.0 | 2560×1440 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| M270DAN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.1 | AUO | 27.0 | 2560×1440 |
| M270H1-L01 | Innolux | 27.0 | 1920×1080 |
