| Nombor Bahagian | G190EAN01.6 |
| Jenama | AUO |
| Saiz | 19.0 |
| Permohonan | Industrial Medical I |
| Resolusi | 1280×1024 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AUO |
| model | G190EAN01.6 |
| saiz pepenjuru | 19.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×1024 [SXGA] 86PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 376.32(H)×301.056(V) mm |
| garis besar malap. | 396(H)×324(V) ×15.8(D) mm |
| kawasan bezel | 380.32(H)×305.06(V) mm |
| rawatan | Antiglare |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 13/12 (Typ.)(Tr/Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod operasi | AHVA, Normally Black, Transmissive |
| warna sokongan | 16.7M 72% NTSC |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat badan | 1.70±0.15Kgs |
| direka untuk | Industrial Medical Imaging Outdoor High Brightness |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (2 ch, 8-bit) |
| bekalan kuasa | 5.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
