G190EG01 V1

G190EG01 V1
G190EG01 V1
G190EG01 V1
G190EG01 V1 thumb G190EG01 V1 thumb G190EG01 V1 thumb
Jenama
AUO
Saiz
19.0
Permohonan
GM
Resolusi
1280×1024
Komposisi
LCM
Kecerahan
350
CR
1000:1
Warna
16.7M
Lampu latar
WLED
Antara muka
LVDS
In Stock
7098
Spesifikasi

Nombor Bahagian G190EG01 V1
JenamaAUO
Saiz19.0
PermohonanGM
Resolusi1280×1024
KomposisiLCM
Kecerahan350
CR1000:1
Warna16.7M
Lampu latarWLED
Antara mukaLVDS
jenama panelAUO
model panelG190EG01 V1
jenis panel a-Si TFT-LCD , LCM
saiz panel19.0 inch
resolusi1280(RGB)×1024 , SXGA
mod paparanTN, Normally White, Transmissive
kawasan aktif376.32×301.056 mm
garis besar396×324×18.3 mm
permukaanAntiglare, Hard coating (3H)
kecerahan350 cd/m² (Typ.)
nisbah kontras1000:1 (Typ.)
warna paparan16.7M (6-bit + Hi-FRC), CIE193172%
masa tindak balas3.6/1.4 (Typ.)(Tr/Td)
sudut pandangan85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (2 ch, 8-bit), 30 pins
voltan masukan5.0V (Typ.)
permohonanGM
Model Keluarga
G190EAN01.0 AUO 19.0 1280×1024
G190EG01 V0 AUO 19.0 1280×1024
G190EG01 V1 AUO 19.0 1280×1024
G190EG01 V2 AUO 19.0 1280×1024
G190EG02 V0 AUO 19.0 1280×1024
G190EG02 V1 AUO 19.0 1280×1024
G190ETN01.1 AUO 19.0 1280×1024
G190ETN01.2 AUO 19.0 1280×1024
G190ETN01.4 AUO 19.0 1280×1024
G190ETN02.0 AUO 19.0 1280×1024
