G150XTN03.1

G150XTN03.1
G150XTN03.1
G150XTN03.1
G150XTN03.1 thumb G150XTN03.1 thumb G150XTN03.1 thumb
Jenama
AUO
Saiz
15.0
Permohonan
IA
Resolusi
1024×768
Komposisi
LCM
Kecerahan
250
CR
500:1
Warna
262K/16.2M
Lampu latar
WLED
Antara muka
LVDS
In Stock
8842
Spesifikasi

Nombor Bahagian G150XTN03.1
JenamaAUO
Saiz15.0
PermohonanIA
Resolusi1024×768
KomposisiLCM
Kecerahan250
CR500:1
Warna262K/16.2M
Lampu latarWLED
Antara mukaLVDS
jenama panelAUO
model panelG150XTN03.1
jenis panel a-Si TFT-LCD , LCM
saiz panel15.0 inch
resolusi1024(RGB)×768 , XGA
mod paparanTN, Normally White, Transmissive
kawasan aktif304.128×228.096 mm
garis besar326.5×253.5×12 mm
permukaanAntiglare, Hard coating (3H)
kecerahan250 cd/m² (Typ.)
nisbah kontras500:1 (Typ.)
warna paparan262K/16.2M (6-bit / 6-bit + FRC), CIE193160%
masa tindak balas6/2 (Typ.)(Tr/Td)
sudut pandangan45/45/20/40 (Typ.)(CR≥10)(L/R/U/D)
kekerapan60Hz
jenis lampuWLEDEmbedded (LED Driver)
antara muka isyaratLVDS (1 ch, 6/8-bit), 20 pins
voltan masukan3.3V (Typ.)
permohonanIA
Model Keluarga
G150XG01 V0 AUO 15.0 1024×768
G150XG02 V0 AUO 15.0 1024×768
G150XGE-L06 Innolux 15.0 1024×768
G150XGE-L07 Innolux 15.0 1024×768
G150XTN02.0 AUO 15.0 1024×768
G150XTN03.0 AUO 15.0 1024×768
G150XTN05.0 AUO 15.0 1024×768
G150XTN06.4 AUO 15.0 1024×768
G150XTT01.0 AUO 15.0 1024×768
G150XVN01.0 AUO 15.0 1024×768
