| Nombor Bahagian | G101STN01.7 |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | AUO |
| saiz pepenjuru | 10.1 inch |
| format piksel | 1024(RGB)×600 [WSVGA] 117PPI |
| kawasan aktif | 222.72(H)×125.28(V) mm |
| kecerahan | - |
| arah pandang | - |
| sudut pandangan | 70/70/60/60 (Typ.)(CR≥10) |
| warna sokongan | 262K/16.7M 45% NTSC |
| berat badan | - |
| kadar bingkai | - |
| persekitaran | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | G101STN01.7 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | - |
| nisbah kontras | 500:1 (Typ.) (TM) |
| masa tindak balas | - |
| mod operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED |
| direka untuk | Industrial |
| panel sentuh | Without |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| G101STN01.0 | AUO | 10.1 | 1024×600 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| G101STN01.3 | AUO | 10.1 | 1024×600 |
| LP101WX1-SLB1 | LG Display | 10.1 | 1280×800 |
| M101NWT4 R3 | IVO | 10.1 | 1024×600 |
| Q101IRE-LA1 | Innolux | 10.1 | 1280×800 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
