| Nombor Bahagian | G101EAN02.1 |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AUO |
| saiz pepenjuru | 10.1 inch |
| format piksel | 1280(RGB)×800 [WXGA] 149PPI |
| kawasan aktif | 216.96(H)×135.6(V) mm |
| kawasan bezel | - |
| kecerahan | 400 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 50% NTSC |
| berat badan | 195g (Max.) |
| kadar bingkai | 60Hz |
| jenis antara muka | LVDS (1 ch, 8-bit) , 40 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
| model | G101EAN02.1 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 227.72(H)×147.8(V) ×4.8(D) mm |
| rawatan | Hard coating |
| nisbah kontras | 800:1 (Typ.) (TM) |
| masa tindak balas | 29 (Typ.)(Tr+Td) |
| mod operasi | AHVA, Normally Black, Transmissive |
| sumber cahaya | WLED , 30K hours , With LED Driver |
| direka untuk | Industrial |
| panel sentuh | Without |
