| Nombor Bahagian | G070VAN01.1 |
| Jenama | AUO |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1300:1 |
| Warna | 262K/16.7M |
| Lampu latar | 7S2P |
| Antara muka | LVDS |
| pengilang | AUO |
| saiz skrin | 7.0 inch |
| nombor piksel | 800×480(RGB) (WVGA) 133PPI |
| kawasan aktif (mm) | 152.4 × 91.44 (H×V) |
| kawasan bezel (mm) | 154.2 × 93.24 (H×V) |
| kecerahan | 200 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 262K/16.7M 60% NTSC |
| jisim | 160g (Typ.) |
| kadar segar semula | 60Hz |
| jenis isyarat | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| nama model | G070VAN01.1 |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Horizontal Stripe |
| garis besar (mm) | 166.6 × 107 × 10 (H×V×D) |
| rawatan | Antiglare |
| nisbah kontras | 1300 : 1 (Typ.) (TM) |
| tindak balas | 11/19 (Max.)(Tr/Td) ms |
| mod kerja | AHVA, Normally Black, Transmissive |
| lampu latar | 7S2P WLED , 30K hours , No Driver |
| digunakan untuk | Industrial |
| skrin sentuh | Without |
