| Nombor Bahagian | FG050020DNCWBG01 |
| Jenama | Data Image |
| Saiz | 5.0 |
| Permohonan | Industrial |
| Resolusi | 320×234 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | Data Image |
| saiz panel | 5.0" |
| resolusi | 320(RGB)×234, 79PPI |
| kawasan paparan | 102.72(W)×74.53(H) mm |
| saiz garis besar | 126.6(W)×92.4(H) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandangan | 60/60/40/60 (Typ.)(CR≥10) |
| pandangan terbaik pada | - |
| warna paparan | 262K |
| kekerapan | 60Hz |
| berat badan | 168g (Typ.) |
| model panel | FG050020DNCWBG01 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 107(W)×78.9(H) mm |
| permukaan | Antiglare |
| nisbah kontras | 350:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 5/25 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 20K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
