| Nombor Bahagian | ES050YMM-A00 |
| Jenama | BOE |
| Saiz | 5.0 |
| Permohonan | Round Display Instru |
| Resolusi | 1080×1080 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1300:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| pengilang | BOE |
| nama model | ES050YMM-A00 |
| saiz skrin | 5.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1080(RGB)×1080 215PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 127.008 × 127.008 (H×V) |
| garis besar (mm) | 143 × 140 × 4.45 (H×V×D) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 1300 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| tindak balas | 40 (Max.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 80% NTSC |
| lampu latar | WLED , No Driver |
| jisim | - |
| digunakan untuk | Round Display Instruments & Meters Home Appliance |
| kadar segar semula | 60Hz |
| skrin sentuh | PCAP |
| Storage Temp.: -30 ~ 75 °C Operating Temp.: -20 ~ 60 °C |
