| Nombor Bahagian | DMF50260NFU-FW-27 |
| Jenama | OPTREX |
| Saiz | 9.4 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | FSTN-LCD , LCM |
| Kecerahan | |
| CR | 14:1 |
| Warna | Monochrome |
| Lampu latar | - |
| Antara muka | |
| jenama panel | OPTREX |
| saiz panel | 9.4" |
| resolusi | 640×480, VGA, 84PPI |
| kawasan paparan | 191.97(W)×143.97(H) mm |
| kecerahan | - |
| sudut pandangan | - |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | Monochrome |
| kekerapan | 70Hz |
| berat badan | - |
| model panel | DMF50260NFU-FW-27 |
| jenis panel | FSTN-LCD , LCM |
| format piksel | Rectangle |
| pembukaan bezel | - |
| nisbah kontras | 14:1 (Typ.) (TM) |
| mod paparan | STN, Black/White mode, Transmissive |
| masa tindak balas | 210/120 (Typ.)(Tr/Td) |
| jenis lampu | |
| skrin sentuh | Without |
| permohonan | Industrial |
