| Nombor Bahagian | SP24V001 |
| Jenama | KOE |
| Saiz | 9.4 |
| Permohonan | IA |
| Resolusi | 640×480 |
| Komposisi | LCM |
| Kecerahan | 110 |
| CR | 20:1 |
| Warna | Monochrome |
| Lampu latar | CCFL |
| Antara muka | Parallel Data |
| jenama panel | HITACHI |
| model panel | SP24V001 |
| jenis panel | FSTN-LCD , LCM |
| saiz panel | 9.4 inch |
| resolusi | 640×480 , VGA |
| mod paparan | STN, Black/White (Negative), Transmissive |
| kawasan aktif | 191.97×143.97 mm |
| garis besar | 257.5×174×7 mm |
| permukaan | Antiglare |
| kecerahan | 110 cd/m² (Typ.) |
| nisbah kontras | 20:1 (Typ.) |
| warna paparan | Monochrome |
| masa tindak balas | 160/110 (Typ.)(Tr/Td) |
| sudut pandangan | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | Parallel Data (4-bit), 15 pins |
| voltan masukan | 3.3/5.0V (Typ.)(VDD) |
| permohonan | IA |
