| Nombor Bahagian | DMF-50174 |
| Jenama | OPTREX |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 320×240 |
| Komposisi | STN-LCD, LCM |
| Kecerahan | |
| CR | |
| Warna | Monochrome |
| Lampu latar | CCFL |
| Antara muka | Parallel |
| jenama | OPTREX |
| model | DMF-50174 |
| saiz pepenjuru | 5.7 inch |
| menaip | STN-LCD, LCM |
| format piksel | 320×240 [QVGA] 70PPI |
| konfigurasi | Rectangle |
| kawasan aktif | 115.17(H)×86.37(V) mm |
| garis besar malap. | 174(H)×112(V) ×14(D) mm |
| kawasan bezel | 122.0(H)×92.0(V) mm |
| rawatan | - |
| arah pandang | - |
| masa tindak balas | - |
| sudut pandangan | - |
| mod operasi | STN |
| warna sokongan | Monochrome |
| sumber cahaya | CCFL , W/O Driver |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 70Hz |
| panel sentuh | Without |
| jenis antara muka | Parallel Data (1ch, 4-bit) , 14 pins Connector |
| bekalan kuasa | 5.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
