| Nombor Bahagian | DLC0700EZG-1 |
| Jenama | Other |
| Saiz | 7.0 |
| Permohonan | DPF |
| Resolusi | 800×480 |
| Komposisi | LCM |
| Kecerahan | 280 |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | DLC |
| model panel | DLC0700EZG-1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 800(RGB)×480 , WVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 154.08×85.92 mm |
| garis besar | 164.9×100×6 mm |
| permukaan | |
| kecerahan | 280 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| masa tindak balas | 10/15 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 3S6PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 6/8-bit), 50 pins |
| voltan masukan | 3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| permohonan | DPF |
| DLC0700BZG-7 | Other | 7.0 | 800×480 |
| DLC0700CZG-6 | Other | 7.0 | 800×480 |
| DLC0700DDG-4 | Other | 7.0 | 800×480 |
| DLC0700EZG-2 | Other | 7.0 | 800×480 |
| DLC0700EZG-T-2 | Other | 7.0 | 800×480 |
| DLC0700FDG-T-6 | Other | 7.0 | 800×480 |
| DLC0700MIG | Other | 7.0 | 800×480 |
| DLC0700OZG-T-1 | Other | 7.0 | 800×480 |
| DLC0700WZG | Other | 7.0 | 1200×1920 |
| DLC0700YZG-1 | Other | 7.0 | 1024×600 |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| A104SN03 V1 | AUO | 10.4 | 800×600 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| EJ080NA-04B | Innolux | 8.0 | 1024×768 |
| HSD084ISN1-A01 | HannStar | 8.4 | 800×600 |
| HSD090IDW1-A00 | HannStar | 9.0 | 800×480 |
| HSD101PFW2-A00 | HannStar | 10.1 | 1024×600 |
| PM070WM3 | E Ink | 7.0 | 800×480 |
| TM102WV-A02-03 | SANYO | 10.2 | 800×480 |
