| Nombor Bahagian | DLC0430LZG-T |
| Jenama | Other |
| Saiz | 4.3 |
| Permohonan | PND |
| Resolusi | 480×272 |
| Komposisi | LCM |
| Kecerahan | 280 |
| CR | 550:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | TTL |
| jenama panel | DLC |
| model panel | DLC0430LZG-T |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 4.3 inch |
| resolusi | 480(RGB)×272 , WQVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 95.04×53.856 mm |
| garis besar | 105.5×67.2×4.3 mm |
| permukaan | Hard coating (3H) |
| kecerahan | 280 cd/m² (Typ.) |
| nisbah kontras | 550:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Hi-FRC), CIE193150% |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 5S2PWLEDWithout Driver |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PND |
