| Nombor Bahagian | COM55T5103RSP |
| Jenama | CASIO |
| Saiz | 5.5 |
| Permohonan | Industrial |
| Resolusi | 320×234 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 60:1 |
| Warna | Full |
| Lampu latar | 1 |
| Antara muka | Analog |
| jenama panel | CASIO |
| saiz panel | 5.5" |
| resolusi | 320(RGB)×234, 72PPI |
| kawasan paparan | 110.4(W)×83.538(H) mm |
| saiz garis besar | 163(W)×115(H) ×32.5(D) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandangan | 35/35/30/35 (Typ.)(CR≥10) |
| pandangan terbaik pada | 12 o'clock |
| warna paparan | Full color |
| kekerapan | 60Hz |
| berat panel | 400g (Typ.) |
| antara muka isyarat | Analog RGB , 12 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -10 ~ 60 °C |
| model panel | COM55T5103RSP |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | - |
| nisbah kontras | 60:1 (Min.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | - |
| jenis lampu | 1 pcs CCFL , With Inverter |
| skrin sentuh | Without |
| permohonan | Industrial |
