| Nombor Bahagian | CLAA080WK02 XN |
| Jenama | CPT |
| Saiz | 8.0 |
| Permohonan | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | CPT |
| model | CLAA080WK02 XN |
| saiz pepenjuru | 8.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×720 [WXGA] 183PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 177.024(H)×99.576(V) mm |
| garis besar malap. | 186.5(H)×117.22(V) ×13.1(D) mm |
| kawasan bezel | 179.03(H)×101.58(V) mm |
| rawatan | Antiglare (Haze 25%) |
| kecerahan | 600 cd/m² (Typ.) |
| nisbah kontras | 900:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | HFFS, Normally Black, Transmissive |
| warna sokongan | 262K/16.7M 70% NTSC |
| sumber cahaya | WLED [5S4P] , 30K hours , W/O Driver |
| berat badan | TBD |
| direka untuk | Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| bekalan kuasa | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| persekitaran | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| CLAA080XA01BW | CPT | 8.0 | 1024×768 |
