| Nombor Bahagian | CLAA042JD02 XN |
| Jenama | CPT |
| Saiz | 4.2 |
| Permohonan | Automotive Display |
| Resolusi | 480×272 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | |
| pengilang | CPT |
| saiz skrin | 4.2 inch |
| nombor piksel | 480(RGB)×272 (WQVGA) 131PPI |
| kawasan aktif (mm) | 92.88 × 52.632 (H×V) |
| kawasan bezel (mm) | 94.48 × 54.27 (H×V) |
| kecerahan | 700 (Typ.)(cd/m²) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 262K |
| jisim | 97.4g (Max.) |
| kadar segar semula | 60Hz |
| nama model | CLAA042JD02 XN |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 102.5 × 67 × 11.3 (H×V×D) |
| rawatan | Antiglare |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| mod kerja | HFFS, Normally Black, Transmissive |
| tindak balas | 25 (Max.)(Tr+Td) ms |
| lampu latar | WLED , 50K hours , No Driver |
| digunakan untuk | Automotive Display |
| skrin sentuh | Without |
| HVA42WV1-M00 | HYDIS | 4.2 | 480×800 |
| LQ042B5DG02 | SHARP | 4.2 | 400×96 |
| LQ042T5DZ01 | SHARP | 4.2 | 480×272 |
| LQ042T5DZ01A | SHARP | 4.2 | 480×272 |
| LQ042T5DZ11 | SHARP | 4.2 | 480×272 |
| LT042MDV5000 | JDI | 4.2 | 768×1280 |
