| Nombor Bahagian | C080VTN04.0 |
| Jenama | AUO |
| Saiz | 8.0 |
| Permohonan | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | AUO |
| model | C080VTN04.0 |
| saiz pepenjuru | 8.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 115PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 175.2(H)×105.12(V) mm |
| garis besar malap. | - |
| kawasan bezel | - |
| rawatan | Antiglare |
| arah pandang | - |
| masa tindak balas | 15/20 (Typ.)(Tr/Td) |
| sudut pandangan | 60/60/40/60 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K |
| sumber cahaya | WLED |
| berat badan | - |
| direka untuk | Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | - |
| jenis antara muka | Parallel RGB (1 ch, 6-bit) , 60 pins Connector |
| persekitaran | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
