| Nombor Bahagian | BV055HDM-T00 |
| Jenama | BOE |
| Saiz | 5.5 |
| Permohonan | Mobile Phone |
| Resolusi | 720×1280 |
| Komposisi | Assembly, a-Si TFT |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | - |
| Antara muka | |
| pengilang | BOE |
| nama model | BV055HDM-T00 |
| saiz skrin | 5.5 inch |
| jenis skrin | Assembly, a-Si TFT-LCD |
| nombor piksel | 720(RGB)×1280 (WXGA) 268PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 68.04 × 120.96 (H×V) |
| garis besar (mm) | - |
| kecerahan | - |
| nisbah kontras | 1200 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| tindak balas | 25/25 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 70% NTSC |
| lampu latar | |
| jisim | - |
| digunakan untuk | Mobile Phone |
| kadar segar semula | 60Hz |
| skrin sentuh | On-Cell Touch |
| 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| CLAN055WA41 3XB | CPT | 5.5 | 720×1280 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| LH550WF4-SJ11 | LG Display | 5.5 | 1080×1920 |
| LQ055T3SX02 | SHARP | 5.5 | 1080×1920 |
| LQ055T3SX04 | SHARP | 5.5 | 1080×1920 |
| LS055R1SX04 | SHARP | 5.5 | 1440×2560 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| PW056XU1 | E Ink | 5.5 | 480×234 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
