| Nombor Bahagian | BV045FHM-L00-1S00 |
| Jenama | BOE |
| Saiz | 4.5 |
| Permohonan | Mobile Phone |
| Resolusi | 1080×1620 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | BOE |
| model | BV045FHM-L00-1S00 |
| saiz pepenjuru | 4.5 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1080(RGB)×1620 434PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 63.115(H)×94.673(V) mm |
| garis besar malap. | 68.14(H)×104.97(V) ×3(D) mm |
| kawasan bezel | - |
| rawatan | Anti Fingerprint |
| kecerahan | 580 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 50 (Max.)(G to G) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | ADS, Normally Black, Transmissive |
| warna sokongan | 16.7M 100% sRGB |
| sumber cahaya | WLED [8S2P] , 15K hours , W/O Driver |
| berat badan | TBD |
| direka untuk | Mobile Phone |
| kadar bingkai | 60Hz |
| panel sentuh | In-Cell Touch |
| Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
