| Nombor Bahagian | BB050HDG-TC1-6D00 |
| Jenama | BOE |
| Saiz | 5.0 |
| Permohonan | Mobile Phone |
| Resolusi | 720×1280 |
| Komposisi | AM-OLED, OLED |
| Kecerahan | |
| CR | 17000:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antara muka | MIPI |
| jenama panel | BOE |
| model panel | BB050HDG-TC1-6D00 |
| saiz panel | 5.0" |
| jenis panel | AM-OLED, OLED |
| resolusi | 720(RGB)×1280, WXGA, 295PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 61.92(W)×110.08(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 64.12(W)×116.72(H) mm |
| permukaan | Hard coating |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 17000:1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Min.) |
| mod paparan | OLED |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | - |
| warna paparan | 16.7M 101% NTSC |
| jenis lampu | self , 10K hours |
| kekerapan | 60Hz |
| skrin sentuh | On-Cell Touch |
| ic pemandu | COG Built-in RM67120 |
| berat panel | TBD |
| permohonan | Mobile Phone |
| antara muka isyarat | MIPI (4 data lanes) |
| voltan masukan | 2.8/1.8/6.0/4.6/-3.4V (Typ.)(VCI/VDDIO/AVDD/ELVDD/ELVSS) |
| persekitaran | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
