| Nombor Bahagian | B140QAN01.1 |
| Jenama | AUO |
| Saiz | 14.0 |
| Permohonan | NBPC |
| Resolusi | 2560×1440 |
| Komposisi | LCM |
| Kecerahan | 340 |
| CR | 700:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | AUO |
| model panel | B140QAN01.1 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 14.0 inch |
| resolusi | 2560(RGB)×1440 , Quad-HD |
| mod paparan | AHVA, Normally Black, Transmissive |
| kawasan aktif | 309.35×174.01 mm |
| garis besar | 320.4×205.1×2.6 mm |
| gaya bentuk | Slim (PCBA Flat, Depth ≤3.2mm) |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 340 cd/m² (Typ.) |
| nisbah kontras | 700:1 (Typ.) |
| warna paparan | 16.7M (8-bit), CIE193172% |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | eDP (4 Lanes), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
