| Nombor Bahagian | B101EAN01.3 |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | PAD |
| Resolusi | 1280×800 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama panel | AUO |
| model panel | B101EAN01.3 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.1 inch |
| resolusi | 1280(RGB)×800 , WXGA |
| mod paparan | AHVA, Normally Black, Transmissive |
| kawasan aktif | 216.96×135.6 mm |
| garis besar | 228.6×149.2×4.4 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) |
| warna paparan | 16.7M (6-bit + Hi-FRC), CIE193150% |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 6S6PWLEDWithout Driver |
| antara muka isyarat | MIPI (4 data lanes), 39 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PAD |
