| Nombor Bahagian | AT101WSM-N11-58P0 |
| Jenama | BOE |
| Saiz | 10.1 |
| Permohonan | Automotive Display |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | BOE |
| model | AT101WSM-N11-58P0 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×600 [WSVGA] 117PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 222.72(H)×125.28(V) mm |
| garis besar malap. | 235(H)×144.9(V) ×5.44(D) mm |
| kawasan bezel | 226(H)×128.6(V) mm |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 25 (Typ.)(Tr+Tf) |
| sudut pandangan | 80/80/60/70 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K/16.7M 50% NTSC |
| sumber cahaya | WLED [3S14P] , 20K hours , W/O Driver |
| berat badan | 300g (Max.) |
| direka untuk | Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| bekalan kuasa | 3.3/11/21/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
