| Nombor Bahagian | ASI545FB01-0 |
| Jenama | Samsung |
| Saiz | 55 |
| Permohonan | DID |
| Resolusi | 1920×1080 |
| Komposisi | OLED |
| Kecerahan | 500 |
| CR | |
| Warna | 1.07B |
| Lampu latar | self |
| Antara muka | LVDS |
| jenama panel | SAMSUNG |
| model panel | ASI545FB01-0 |
| jenis panel | TOLED , OLED |
| saiz panel | 55 inch |
| resolusi | 1920×1080(RGB) , FHD |
| kawasan aktif | 1209.6×680.4 mm |
| garis besar | 1219.4×697 mm, Videowall Seam 9.8 mm |
| permukaan | Hard coating (2H), Antireflection |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | |
| warna paparan | 1.07B (10-bit), CIE1931100% |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| antara muka isyarat | LVDS (2 ch, 10-bit), 51 pins |
| voltan masukan | 12.0V (Typ.) |
| permohonan | DID |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC550EUB-SCA1 | LG Display | 55 | 1920×1080 |
| LC550EUD-SCA1 | LG Display | 55 | 1920×1080 |
| LC550EUG-PEF1 | LG Display | 55 | 1920×1080 |
| LTA550HJ05 | Samsung | 55 | 1920×1080 |
| LTI550HN03 | Samsung | 55 | 1920×1080 |
| T546HW02 V1 | AUO | 55 | 1920×1080 |
| T550QVD01.0 | AUO | 55 | 3840×2160 |
| V546H1-LS1 | Innolux | 55 | 1920×1080 |
| ASI545FB01-0 | Samsung | 55 | 1920×1080 |
| LD470DXS-SCA1 | LG Display | 47 | 1366×768 |
| LD470DXS-SCB1 | LG Display | 47 | 1366×768 |
| LD550DUN-THB3 | LG Display | 55 | 1920×1080 |
| LTI460HN01 | Samsung | 46 | 1920×1080 |
| LTI460HN07 | Samsung | 46 | 1920×1080 |
| LTI460HN09 | Samsung | 46 | 1920×1080 |
| LTI460HN10 | Samsung | 46 | 1920×1080 |
| LTI460HN11 | Samsung | 46 | 1920×1080 |
| LTI550HN14 | Samsung | 55 | 1920×1080 |
