| Nombor Bahagian | AM800480R3TMQW-B2H |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AMPIRE |
| model | AM800480R3TMQW-B2H |
| saiz pepenjuru | 7.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800(RGB)×480 [WVGA] 133PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 152.4(H)×91.44(V) mm |
| garis besar malap. | - |
| kecerahan | - |
| nisbah kontras | 400:1 (Typ.) (TM) |
| arah pandang | 6 o'clock |
| masa tindak balas | 5/11 (Typ.)(Tr/Td) |
| sudut pandangan | 70/70/60/70 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K 45% NTSC |
| sumber cahaya | WLED |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 8-bit) , 20 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
