| Nombor Bahagian | AM-800480RBTMQW-TA1H-A |
| Jenama | AMPIRE |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | 3S10P |
| Antara muka | LVDS |
| jenama panel | AMPIRE |
| model panel | AM-800480RBTMQW-TA1H-A |
| saiz panel | 7.0" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 800(RGB)×480, WVGA, 133PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 152.4(W)×91.44(H) mm |
| pembukaan bezel | 155.3(W)×94.3(H) mm |
| saiz garis besar | 165(W)×104.44(H) ×8.06(D) mm |
| permukaan | - |
| kecerahan | 255 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) (TM) |
| sudut pandangan | 70/70/70/60 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 6 o'clock |
| masa tindak balas | 5/11 (Typ.)(Tr/Td) |
| warna paparan | 262K |
| jenis lampu | 3S10P WLED , 40K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | PCAP |
| berat panel | TBD |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 6-bit) , 20 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
