| Nombor Bahagian | AM-800480BCTMQW-T00H |
| Jenama | AMPIRE |
| Saiz | 5.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 600:1 |
| Warna | 16.7M |
| Lampu latar | 6S2P |
| Antara muka | Parallel |
| pengilang | AMPIRE |
| saiz skrin | 5.0 inch |
| nombor piksel | 800(RGB)×480 (WVGA) 188PPI |
| kawasan aktif (mm) | 108 × 64.8 (H×V) |
| kecerahan | 340 cd/m² (Typ.) |
| sudut pandangan | 75/75/60/70 (Typ.)(CR≥10) |
| pandangan yang baik di | 6 o'clock |
| kedalaman warna | 16.7M 52% NTSC |
| jisim | - |
| kadar segar semula | 60Hz |
| jenis isyarat | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| nama model | AM-800480BCTMQW-T00H |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 129.9 × 86.7 × 7.18 (H×V×D) |
| nisbah kontras | 600 : 1 (Typ.) (TM) |
| tindak balas | 4/12 (Typ.)(Tr/Td) ms |
| mod kerja | TN, Normally White, Transmissive |
| lampu latar | 6S2P WLED , 50K hours , No Driver |
| digunakan untuk | Industrial |
| skrin sentuh | PCAP |
