| Nombor Bahagian | AM-19201200FTZQW-T05 |
| Jenama | AMPIRE |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1920×1200 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | AMPIRE |
| saiz panel | 10.1" |
| resolusi | 1920(RGB)×1200, WUXGA, 224PPI |
| kawasan paparan | 216.806(W)×135.504(H) mm |
| saiz garis besar | 227.72(W)×146.13(H) ×7.2(D) mm |
| kecerahan | 320 cd/m² (Typ.) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 50% NTSC |
| kekerapan | 60Hz |
| berat panel | - |
| antara muka isyarat | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | AM-19201200FTZQW-T05 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | - |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | AHVA, Normally Black, Transmissive |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 30K hours , With LED Driver |
| skrin sentuh | PCAP |
| permohonan | Industrial |
