| Nombor Bahagian | AM-19201200CTZQW-02 |
| Jenama | AMPIRE |
| Saiz | 10.1 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1920×1200 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AMPIRE |
| model | AM-19201200CTZQW-02 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1920(RGB)×1200 [WUXGA] 225PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 216.576(H)×135.36(V) mm |
| garis besar malap. | 244.8(H)×155.3(V) ×7.07(D) mm |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | AHVA, Normally Black, Transmissive |
| warna sokongan | 16.7M 49% NTSC |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat badan | - |
| direka untuk | Industrial Outdoor High Brightness |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (2 ch, 8-bit) , 45 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
