| Nombor Bahagian | AM-1024768TTMQW-T00H |
| Jenama | AMPIRE |
| Saiz | 10.4 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AMPIRE |
| model | AM-1024768TTMQW-T00H |
| saiz pepenjuru | 10.4 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1024(RGB)×768 [XGA] 123PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 211.2(H)×158.4(V) mm |
| garis besar malap. | 236(H)×176.9(V) ×7.9(D) mm |
| kawasan bezel | 214.8(H)×162.0(V) mm |
| rawatan | Antiglare |
| kecerahan | 280 cd/m² (Typ.) |
| nisbah kontras | 900:1 (Typ.) (TM) |
| arah pandang | 6 o'clock |
| masa tindak balas | 16 (Typ.)(Tr+Td) |
| sudut pandangan | 75/75/75/75 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K/16.7M |
| sumber cahaya | WLED [4 strings] , 30K hours , With LED Driver |
| berat badan | 290g (Max.) |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | 4-wire Resistive Touch |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
