| Nombor Bahagian | AC101TB01 |
| Jenama | Mitsubishi |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | Mitsubishi |
| model | AC101TB01 1 Compatible |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×800 [WXGA] 149PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 216.96(H)×135.6(V) mm |
| garis besar malap. | 231(H)×153.5(V) ×10.25(D) mm |
| kawasan bezel | - |
| rawatan | Antiglare |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | - |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | SWV, Normally Black, Transmissive |
| warna sokongan | 16.2M 50% NTSC |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C |
