| Nombor Bahagian | AC057VK04 |
| Jenama | Mitsubishi |
| Saiz | 5.7 |
| Permohonan | Industrial |
| Resolusi | 640×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 600:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama panel | Mitsubishi |
| model panel | AC057VK04 |
| saiz panel | 5.7" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 640(RGB)×480, VGA, 141PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 115.2(W)×86.4(H) mm |
| pembukaan bezel | 118.1(W)×89.3(H) mm |
| saiz garis besar | 127(W)×100(H) mm |
| permukaan | Antiglare, Hard coating (2H) |
| kecerahan | 520 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/60 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | 6 o'clock |
| masa tindak balas | 4/12 (Typ.)(Tr/Td) |
| warna paparan | 262K 48% NTSC |
| jenis lampu | WLED , 50K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 90.0g |
| permohonan | Industrial |
| antara muka isyarat | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
