| Nombor Bahagian | AA106TA01DDE11 |
| Jenama | Mitsubishi |
| Saiz | 10.6 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1280×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | Mitsubishi |
| model | AA106TA01DDE11 |
| saiz pepenjuru | 10.6 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×768 [WXGA] 140PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 231.36(H)×138.816(V) mm |
| garis besar malap. | 250(H)×175(V) ×15.5(D) mm |
| kawasan bezel | - |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 800 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 12/12 (Typ.)(Tr/Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | SWV, Normally Black, Transmissive |
| warna sokongan | 262K/16.7M 50% NTSC |
| sumber cahaya | WLED , 100K hours , With LED Driver |
| berat badan | 670g (Typ.) |
| direka untuk | Industrial Outdoor High Brightness |
| kadar bingkai | 60Hz |
| panel sentuh | PCAP |
| Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD106EWNN | TOSHIBA | 10.6 | 1280×768 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN106W2-L01 | Samsung | 10.6 | 1280×768 |
