| Nombor Bahagian | A030VAC01.1 |
| Jenama | AUO |
| Saiz | 3.0 |
| Permohonan | Digital Still Camera |
| Resolusi | 720×480 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 6S1P |
| Antara muka | Serial |
| pengilang | AUO |
| nama model | A030VAC01.1 |
| saiz skrin | 3.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 720(RGB)×480 287PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 63.72 × 42.48 (H×V) |
| garis besar (mm) | 78 × 51.1 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Hard coating (6H) |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| tindak balas | 18/18 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | - |
| mod kerja | TN, Normally White, Transmissive |
| kedalaman warna | 16.7M 70% NTSC |
| lampu latar | 6S1P WLED , No Driver |
| jisim | 27.0g (Typ.) |
| digunakan untuk | Digital Still Camera Digital Video Camera |
| kadar segar semula | - |
| skrin sentuh | Without |
| jenis isyarat | Serial RGB (8-bit) + SPI , 51 pins FPC |
| bekalan voltan | 1.8/3.0V (Typ.)(VDDIO/VDD) |
| maks. penilaian | Storage Temp.: -25 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| A030DN01 V9 | AUO | 3.0 | 320×240 |
| A030JTN01.1 | AUO | 3.0 | 960×480(dot) |
| AMS300FW01-0 | Samsung | 3.0 | 240×400 |
| C-51505NFJ-SLW-AIN | Kyocera | 3.0 | 20×2 |
| DMC-20261NYJ-LY-CDE-CKN | Kyocera | 3.0 | 20×2 |
| LS030B3UW01 | SHARP | 3.0 | 240×400 |
| LS030B3UX07 | SHARP | 3.0 | 240×400 |
| TD030WHEA1 | TPO | 3.0 | 320×240 |
| TFTMD030011 | JDI | 3.0 | 720×480 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
